Lora smart watch with GPS/BLE

ID: DASQ001Off-The-ShelfCustomizableEnd-product
Location: Shenzhen, China
With BLE/GPS/LoRa functions, can monitor blood oxygen, body temperature, heart rate, blood pressure and stress. Support time automatic calibration, support uplink/downlink data through LORA base station.
Processor: MCU
Wireless: Bluetooth(5.2), GPS, LORA
Power: Battery(650 mAh)
Memory: DRAM(512Kb), FLASH(1Mb)
Sensors: Accelerator, G-sensor, ECG, PPG, Heart rate
Software Specifications: IXFIT
Dimension: 98 mm (L) x 98 mm (W) x 40 mm (H)
Material: Plastic (PC, ABS, ABS+PC, Carbon fiber)(Main body)
(View more specifications)
Price starts from:US$ 106.99/pcs
1 Piece+:
US$ 106.99
for Off-The-Shelf solution
for Customizable solution
Description
Specification
Terms
Supplier Info

The LoRa smart watch is with the healthy monitoring functions like Blood Oxygen, Body Temperature, Heart Rate, Respiration, Stress, Fatigue and Blood Pressure. It has Bluetooth, GPS/ Beidou and LORA communication protocol to realize IoT smart watch function.



Major Functions:



Stress(emotion): Support - algorithm based on HRV

Pedometer sleep: Support

Blood Pressure SPO2: Support red light to measure blood oxygen (measured when quiet)

Respiratory Rate: Support (times per minute)

Blood Pressure: Support (but inaccurate, use with caution, not responsible for accuracy)

Body Temperature: High precision temperature measuring module, with the temperature measuring accuracy of plus or minus 0.2 degrees.

Fatigue: Support, algorithm based on heart rate/sleep/HRV, etc.

Heart rate: The heart rate power consumption is 100 microamp-150 microamp-7*24 hours continuous broadcast is supported when normally turned on.

HRV/RRI: 25HZ sampling rate, broadcast data acquisition and Bluetooth SDK(API) acquisition are both supported.

XYZ Acceleration sensor values: Support SDK/API to obtain the original value of XYZ axis acceleration sensor.

PPG RAWDATA: Support.

Time Automatic Calibration of the wristband in Batches(Bluetooth Base Station): Support.

Time Automatic Calibration of the wristband in Batches(LORA Base Station): Support.

SOS: Support physical button, long press for 5 seconds, broadcast SOS = 1, which will be received by the base station. The cloud platform will make corresponding processing mechanism, which can be accepted by bluetooth base station or LORA base station.

Bluetooth BEACON Broadcast: 300MS broadcast data; support

With the support of the Bluetooth base station:

1. Support time calibration in batches of the base station.

2. Support the display of user information on the bracelet page (or four fields including employee name/company name/department/employee number)

3. Support the message push from the bluetooth base station

4. Store five messages

With LORA base station:

1. Support the uploading of vital signs data to the cloud platform through LORA base station (default transmission frequency: 1 packet of data every 5 min, including vital signs and GPS/BD positioning data)(uplink data)

2. Support the information push from the LORA base station to the watch (downlink data)

3. Support the report from the SOS to the platform through LORA base station

4. The uplink and downlink data are private protocols and do not support LORAWAN



Specification:



Basic Parameter:

Bracelet size (mm) - Bracelet body: 42.5*53*18.5mm

Weight-Bracelet body: 40g

Weight-Watchband body: 22g

Body Temperature Function: Shell temperature detection, high-precision dynamic heart rate detection, tempereature sensing slices with high-thermal conductivity, built-in algorithm, continuous measurement of the shell temperature of the wrist, continuous broadcast, measurement range of 35-42 degrees Celsius, accuracy of plus or minus 0.2 degrees Celsius.



Hardware Parameter:

Chipset Supplier: NORDIC NRF52840+LORA module+GPS/Beidou Module

APP: IXFIT(downloaded from Apple market) support to provide SDK/API for customers to develop apps by themselves.

Compatible System: RTOS ThreadX

FLASH memory: Built-in FLASH 1Mbit, Built-in RAM:512Kbit

Type: TFT IPS

Screen Size: 51.3mm

Touch Type: 2 physical buttons (long press for SOS button and short press for menu switching and message query and selection, etc.) +1 touch button (6 points).



Connection Parameter:

Bluetooth: Bluetooth 5.2



Sensor:

G-Sensor: High-precision sensor, with the operating power consumption of only 100 microamps, support step counting, sleep and other functions.

Heart Rate:High precision heart rate and blood oxygen module.



Battery:

Type: Lithium polymer battery

Capacity: 650mAh.

Charging Method: Magnetic charger (can be matched with 50 centralized charging management boxes)



Other Parameter:

Waterproof Level: IP68

Charging time: 4H

Life time: Heart rate continues to work for 7*24 hours or more (without LORA and GPS)

Appearance material: Main body: plastic, wrist strap: silica gel



Package Size:

Package size (L*W*H) MM: 98*98*40mm

Package weight (g): 140g(including charging accessories for head watchband)

Outer Box Size (L*W*H) : 510*420*230mm

Outer Box Weight (KG): 10.2

Packing Quantity (sets): 100 sets













Function Specifications

  • Processor: MCU
  • Wireless: Bluetooth(5.2), GPS, LORA
  • Power: Battery(650 mAh)
  • Memory: DRAM(512Kb), FLASH(1Mb)
  • Sensors: Accelerator, G-sensor, ECG, PPG, Heart rate

Software Specifications

IXFIT

Enclosure

  • Dimension: 98 mm (L) x 98 mm (W) x 40 mm (H)
  • Material: Plastic (PC, ABS, ABS+PC, Carbon fiber)(Main body)
  • Product Weight: 140 grams
