Box Size Capture iTOF Laser Dongle for Mobile Cumputer

ID: WSMI003Editor’s PickCustomizableEnd-product
Supplier: Wiseome Inc.
Location: Taipei, Taiwan
This is an instant freight parcel dimension capturer. Customized to pair with mobile computers, it allows users to get the parcel box size in one snapshot by adding this ready feature to the existing device.
Interface: USB, UART
Sensors: iTOF sensor
Software Specifications Options: Android
Contact supplier for quote
for Customizable solution
Description
Specification
Supplier Info



Box Size Measuring Sensor: Sizensor

Real-time three-dimensional data capture technology combining laser ranging and photogrammetry

This is an instant freight parcel dimension capturer. Built for users who are keen on minimize the loading of measuring box sizes in their daily work, such as warehouse manager or shippers, it allows users to get the parcel box size in one snapshot. By using this sensor, users can extract 3D dimension directly from 2D photos simply with their cellphones.



Features

Ÿ   Timesaving: Get the parcel box size in one snapshot

Ÿ   Extract 3D dimension directly from 2D photos

Ÿ   Built-in type Sizensor available:

      Hardware: We develop the add-on accessory (dongle) that contains miniaturized laser module for your mobile devices.

      Software: 3D photogrammetry algorithm and auto recognition API will be provided for customization.

Ÿ   Features on demand: optional features allowed for various needs

Sizensor product solution





Steps for Measurement

Sizensor* utilizes the handheld device camera to detect the cuboid box, gets distance from the laser measure and then calculates the dimensions according the handheld device's pitch angle. All processes are integrated by the Sizensor App.

(*The App is currently only for Android OS handheld devices)

1.      Capturing

2.      Measuring

3.      Calculation





Customized Features

Ÿ   Freight fare calculation

Ÿ   Customized data output

Ÿ   Customized add-on module

Ÿ   Sum-up mode



Specifications for Customized Sizensor Module



Function Specifications Options

  • Interface: USB, UART
  • Sensors: iTOF sensor

Software Specifications Options

Android

Wiseome Inc.

Wiseome Inc. is a startup team incubated by our 44-years-old parent company, Conary Enterprise, who grew during the early period of the semiconductor industry in Taiwan. The development of optoelectronic semiconductors was locked in the 1990s and we had since never looked back. Wiseome Inc. is consisted of young generation of opto-mechanical R&D, electrical device and application software engineering talents. The launch of life-style tech products has been recognized by world-class iF, Red Dot and Taiwan Excellence Awards. Focus on research and development of optical electromechanical applications, the team continued to develop new innovations and span off in 2018. In addition to provide engineering solutions to industrial clients, commercial brands such as “iPin” for laser-guided dimension measure and “VentiFresh” for UV based life-style consumer products were introduced to promote the benefits of the technologies.

Service Types

Mechanical Design
Electronic Design
Software Development – App/Cloud/Machine Learning
Prototyping
Experience
Created own consumer electronic brands iPin and Ventifresh. Patent holder for the smallest laser modules in the industry. Supplied laser modules for spatial measurement and pointer applications for mobile phones. Supplied private label products of laser measurement and UV LED based air sterilizing for consumer sales.

Certification

  • US, EU, JP, Taiwan and China technology and product patents. Various electronic product associated safety certification such as CE, PSE, FCC., etc. iF, Red Dot, Good Design, Taiwan Excellence and Golden Pin Design awards.
