NAU83U25YG

NAU83U25YG is a highly efficient, filter-free, stereo Class-D audio amplifier, which is capable of driving a 4 Ω load with up to 3.0 W output power. This device provides I²C control and I²S audio input with low standby current and fast start-up time.

The NAU83U25YG is ideal for the automotive applications, as it has advanced features like AEC-Q100 grade 2, 80 dB PSRR, 90% efficiency, ultra-low quiescent current (i.e. 2.1 mA at 3.7V for 2 channels) and superior EMI performance.

Target Applications:

•Dashboard
•VSP (Vehicle Sound for Pedestrians)
•AVAS (Acoustic Vehicle Alerting System)
•ADAS (Advanced Driver Assist System)
•eCall / T-box

Key Features:

•Audio Input
-Digital Audio Interface: I²S / PCM Input
-Pin Selectable: I²S Left or Right Channel selection
-Pin Selectable: PCM Time slot
-Sampling Rates: 8 ~ 96 kHz
-80 dB PSRR @ 217 Hz

•Audio Output
-Powerful Stereo Class-D Amplifier
-2 channels of 3.0 W (4Ω @ 5V, 10% THD+N)
-2 channels of 1.32 W (4Ω @ 3.7V, 1% THD+N)
-2 channels of 1.72 W (8Ω @ 5V, 10% THD+N)
-2 channels of 0.75 W (8Ω @ 3.7V, 1% THD+N)
-LLow Output Noise: 18 μVRMS @ 0 dB gain

•Advance/Control Feature
-I²C Control Interface
-Gain Setting: 24 dB ~ -62 dB (plus mute)
-Low Current Shutdown and Standby Modes
-Click-and Pop Suppression

•Operating Characteristics
-Voltage range: 2.5V ~ 5.5V
-Temperature range: -40°C ~ 105°C (AEC-Q100 Automotive Grade 2)
-Low Quiescent Current:
 •2 channels of 2.1 mA @ 3.7V
 •2 channels of 3.2 mA @ 5V

•Package
-QFN-20 (4 x 4 mm)
