WA04T470 JTL
Thick Film RES Array 0402*4, Concave type 0402(1005) 1/16W, 47Ω, ≦±300ppm/⁰C, ±5%
Supplier:
Walsin
Certification:
Specification
Attribute Value
Tolerance
±5%
Termination
Sn base (Lead free)
Resistance
47Ω
Temperature Coefficient
≦±300ppm/⁰C
Power Rating
1/16W
Case Code - inch (mm)
0402(1005)
Package
7" Tape & Reel 10K
Description
The chip-resistor array is constructed in concave type with strong termination and body strength, giving excellent self-alignment ability and reducing solder bridging issues. Available in sizes WA06T( 0603x4), WA04T(0402x4), and WA04U (0402x2), the chip array brings benefit of saving mounting space and reducing the mounting cost, which offers a win-win solution to space-concerned applications.
Features
Product Feature 1
1. High reliability and stability
2. Reduced size of final equipment
3. Lower assembly cost and higher surface mounted efficiency
4. Higher component and equipment reliability
5. Strong body and terminations
6. Excellent performance in surface mounting assembly.
2. Reduced size of final equipment
3. Lower assembly cost and higher surface mounted efficiency
4. Higher component and equipment reliability
5. Strong body and terminations
6. Excellent performance in surface mounting assembly.
