WR01X3003FDL
Thick Film General Purpose RES 01005(0402) 1/32W, 300000Ω, ≦±200ppm/⁰C, ±1%
Supplier:
Walsin
Certification:
Specification
Attribute Value
Tolerance
±1%
Termination
Sn base (Lead free)
Resistance
300000Ω
Temperature Coefficient
≦±200ppm/⁰C
Power Rating
1/32W
Case Code - inch (mm)
01005(0402)
Package
7" Tape & Reel 20K
Description
The resistors are constructed in a high grade ceramic body (aluminum oxide). Internal metal electrodes are added at each end and connected by a resistive paste that is applied to the top surface of the substrate. The composition of the paste is adjusted to give the approximate resistance required and the value is trimmed to within tolerance by laser cutting of this resistive layer.
The resistive layer is covered with a protective coat. Finally, the two external end terminations are added. For ease of soldering the outer layer of these end terminations is Tin solder (Pb free) alloy.
Available sizes from 01005 to 2512 with power rated up to 1W, and Resistance Range from 1 ohm to 10Mohm.
The resistive layer is covered with a protective coat. Finally, the two external end terminations are added. For ease of soldering the outer layer of these end terminations is Tin solder (Pb free) alloy.
Available sizes from 01005 to 2512 with power rated up to 1W, and Resistance Range from 1 ohm to 10Mohm.
Features
Product Feature 1
1. High reliability and stability
2. Reduced size of final equipment
3. Lower assembly costs
4. Higher component and equipment reliability
5. RoHs compliant and lead free products
2. Reduced size of final equipment
3. Lower assembly costs
4. Higher component and equipment reliability
5. RoHs compliant and lead free products
